Intelligent Microphone Manager
MRF912
Wireless charging, secure storage and centralized microphone control for daily teaching use.
Product Overview
Clear, dependable audio for professional spaces
Wireless charging, secure storage and centralized microphone control for daily teaching use.
Technical Information
Technical specifications
English specifications are provided for review. Missing or conflicting source values are marked in the table; confirm these with ARTCK before specifying the product.
| Architecture | Distributed wireless microphone system with dock-mounted antennas separated from decoding electronics |
|---|---|
| Reception | Multiband wireless signal processing |
| Storage | Intelligent locking microphone holder |
| Activation | Pairing and communication preparation during unlock; press any key to activate |
| Charging | Wireless charging; automatic stop when full and automatic recharge after extended discharge |
| Interface | 1 concealed RJ45 connection |
| Wired transmission distance | Up to 50 m over a single network cable |
| Display | Round high-definition color TFT with configurable standby screen |
| Controls | Touch-sensitive buttons and voice prompts |
| IR function | Integrated multi-directional infrared transmitter |
| Installation | Separate interface box and fixed desktop base; no exposed desktop connectors |
| Management | IoT control integration |
View original Chinese specifications
技术参数:
独创分布式无线话筒系统,天线系统与解码处理分离式设计,天线系统前置在充电座,完美解决天线外露及固定、无线信号屏蔽、天线使用距离,等传统无线话筒严重诟病的问题;
锁扣式智能保管;
多频段无线信号接收处理;
话筒解锁即可实现对频、通信等预处理工作,无需额外对频动作,按任意键激活即可使用;
无线充电,智能充电管理,电池充满自动停止充电,以保护电池,延长使用寿命。长时间亏电,自动恢复充满电池,悠长暑假回来,电池也能保持饱满状态;
贴心使用语音提示;
TFT高清圆形彩屏,各种工作状态动态显示;
可定制待机界面;
全触摸感应按键;
集成多方位红外发射功能;
接口:RJ45网口x1,极致简约埋藏式接口设计,防止多接口外露容易被认为破坏;
分离式接口盒设计,桌面部分没有任何外露接插头,防止误插拔和接插头意外脱落;
分离式底座设计,可固定桌面安装,防止移动、挪走、被盗;
火烈鸟仿生设计,优雅、热情、鲜艳,洋溢青春气息;
物联网智能接入控制;
通过一根网线连接话筒智能管家,50米内稳定传输,不受机柜安装位置限制;
产品中心
独创分布式无线话筒系统,天线系统与解码处理分离式设计,天线系统前置在充电座,完美解决天线外露及固定、无线信号屏蔽、天线使用距离,等传统无线话筒严重诟病的问题;
锁扣式智能保管;
多频段无线信号接收处理;
话筒解锁即可实现对频、通信等预处理工作,无需额外对频动作,按任意键激活即可使用;
无线充电,智能充电管理,电池充满自动停止充电,以保护电池,延长使用寿命。长时间亏电,自动恢复充满电池,悠长暑假回来,电池也能保持饱满状态;
贴心使用语音提示;
TFT高清圆形彩屏,各种工作状态动态显示;
可定制待机界面;
全触摸感应按键;
集成多方位红外发射功能;
接口:RJ45网口x1,极致简约埋藏式接口设计,防止多接口外露容易被认为破坏;
分离式接口盒设计,桌面部分没有任何外露接插头,防止误插拔和接插头意外脱落;
分离式底座设计,可固定桌面安装,防止移动、挪走、被盗;
火烈鸟仿生设计,优雅、热情、鲜艳,洋溢青春气息;
物联网智能接入控制;
通过一根网线连接话筒智能管家,50米内稳定传输,不受机柜安装位置限制;
产品中心
Project Support
Need help specifying MRF912?
Tell us about your room, users and system requirements. ARTCK will help you select a compatible solution.
